Figtree Hill is a new master planned community under development at Campbelltown in Sydney’s south-west. Vaughan Infrastructure is currently constructing a new sewer pump station which will serve the future community.

Scope includes:

• Design and construct of all civil, electrical and SCADA integration for Figtree Hill Sewer Pump Station.

• Design of temporary shafts, complex shoring, and sections of scope to improve delivery on site.

• Construction of an in-ground reinforced concrete wet wall 15m deep by 6m diameter.

• Construction of an in-ground precast concrete valve chamber, emergency relief structure (ERS), and an in-ground reinforced concrete inlet maintenance hole (IMH).

• Design of various elements of the works as required by the client.

• Ductile iron pipework (DICL) from the valve chamber to the DN300 x DN200 reducer within the site fence.

• DN150 bypass connection with stop and non-return valves to allow bypass pumping into the sewer pressure main.

• Construction of a 2200mm diameter maintenance hole upstream DN900 pipe which includes inlets for DN300 and DN200 pipework to connect to.

• Installation of scour line, valves and pipework for wastewater, air valve and vent lines, all-weather kiosk, and a main distribution board with facility to receive power supply from the electricity distributor and an emergency generator.

• Installation and integration of soft starter type motor starters, integrated instrumentation, controls, automation and telemetry system (IICATS), remote telemetry unit (RTU) panel and associated controls.

• Control and telemetry systems installed and configured to IICATS requirements.

• Development and implementation of a wastewater commissioning plan and proof of performance testing.

• Emergency duty programmable logic controller (PLC) independent of the RTU as back up to the RTU.

• Supply and installation of natural ventilation system.

• Coordinate the inspection, testing and commissioning of the pump station.
